The main technical parameters
| Model | JS3000 II.5 | JS2000 II | JS1500 II | JS1000 IIB |
|---|---|---|---|---|
| Nominal capacity (L) | 3000 | 2000 | 1500 | 1000 |
| Dry material capacity (L) | 4500 | 3200 | 2400 | 1600 |
| Maximum size of aggregate (mm) | ≤80 | ≤80 | ≤80 | ≤80 |
| Work cycle (s) | 52 | 52 | 52 | 52 |
| Hourly production capacity (m²/h) | ≥180 | ≥120 | ≥90 | ≥60 |
| Drive power (kw) | 2x55 | 2x37 | 2x30 | 2x22 |
| Drive voltage/frequency | AC380V/50HZ | AC380V/50HZ | AC380V/50HZ | AC380V/50HZ |
| Solenoid valve voltage | AC220V/DC24V | AC220V/DC24V | AC220V/DC24V | AC220V/DC24V |
| Motor speed (r/min) | 1450 | 1450 | 1450 | 1450 |
| Spindle speed (r/min) | 26.85 | 26.85 | 22 | 26.85 |
| Number of blades | 48 | 18 | 20 | 16 |
| Whole machine (maximum shape) size: length x width x height | 4110x2530x2254 | 3120x2310x1680 | 2880x2310x1680 | 2660x1950x1230 |
| Model | JS1000IIC | JS750 II | JS500 II |
|---|---|---|---|
| Nominal capacity (L) | 1000 | 750 | 500 |
| Dry material capacity (L) | 1600 | 1200 | 800 |
| Maximum size of aggregate (mm) | ≤80 | ≤80 | ≤80 |
| Work cycle (s) | 52 | 52 | 52 |
| Hourly production capacity (m²/h) | ≥60 | ≥45 | ≥25 |
| Drive power (kw) | 1x37 | 1x30 | 1x18.5 |
| Drive voltage/frequency | AC380V/50HZ | AC380V/50HZ | AC380V/50HZ |
| Solenoid valve voltage | AC220V/DC24V | AC220V/DC24V | AC220V/DC24V |
| Motor speed (r/min) | 1450 | 1450 | 1450 |
| Spindle speed (r/min) | 32.2 | 28 | 35.26 |
| Number of blades | 16 | 16 | 16 |
| Whole machine (maximum shape) size: length x width x height | 3580x2150x3570 | 3580x2150x3370 | 2900x2245x2650 |
